Mercusys 300Mbps Multi-Mode Wireless N Router, 2× Fixed External Antennas, 2× 10/100 Mbps LAN Ports, 1× 10/100 Mbps WAN Port, FEATURE: Access Point Mode, WPS/Reset Button, IPTV, IPv6, Beamforming, MU-MIMO, Parental Controls, Guest Network

Specifications

Network Device Type

Router/Range Extender/Access Point

Data Link Protocol Supports (New)

Wi-Fi + LAN

External Connection Type

1 x WAN (up to 100 Mbps)

Wireless Networking

IEEE 802.11n 2.4 GHz, up to 300 Mbps
IEEE 802.11g 2.4 GHz, up to 54 Mbps
IEEE 802.11a 2.4 GHz, up to 11 Mbps

Encryption Algorithm

WPA-PSK
WPA2-PSK
WPA
WPA2

LAN

2 (RJ-45)

Supported Networking Compliant Standards

IEEE 802.11b
IEEE 802.11g
IEEE 802.11n Wi-Fi 4

Protocols (OSI Model)

PPPoE
IPv4
IPv6
L2TP
PPTP

Application Layer

UPnP

Firewall Functions and Protocols

DMZ Support
MAC address filtering

Router Features

Live Parental Controls
MU-MIMO
Beamforming Technology
DHCP Server

Antenna

External

Wireless LAN Antenna Quantity

2

Built-in Devices

Reset Button

Included Accessories

Power Adapter
Quick Start guide

Cable Included

LAN Cable

WAN

1 (RJ-45)

Power Device Location

External

Maximum Input Current

0.6 A

Maximum Input Voltage

5 V

Width (mm)

114 mm

Height (mm)

26 mm

Depth (mm)

94 mm

External Color

White

Maximum Operating Ambient Temperature

40 °C

Maximum Operating Humidity

90 %

Minimum Operating Ambient Temperature

0 °C

Minimum Operating Humidity

10 %

Warranty Products Returnable

Yes

Warranty Term (month)

24 month(s)

Warranty validation Criteria

Serial Number

Pack Weight Brutto (kg)

0.3 kg

Pack Weight Netto (kg)

0.3 kg

Pieces in pack

1

Box Weight Brutto (kg)

0.3 kg

Retail Packaging Net Weight Carton

0.15 kg

Retail Packaging Net Weight Plastic

0.15 kg

Packs in Box

1

Package Type

Retail

EAN Code

6935364089351

EAN

6935364089351

Warranty

36
